Arc-80S

Urban lighting

Ø560 x H411 80W 9920 lm

Input Voltage: 220VAC (50-60Hz)

Order code : Arc-080S27020ALB0000

Color
Optics

Technical data

specification drawing

DatasheetIES fileDWG file3DS file
  • complies with the European standard EN 60598-1
  • Appliance class III
  • IP67
  • IK07
Installation Urban lighting
Power 80W
Power supply 220 VAC
Lumen output 9920lm
Color 2700K, 3000K, 3500K, 4000K, 5000K, 6000K
Optics 10°, 40°, 60°, diffuse
Material Aluminium
Finishes Black
Efficiency 82%
Ingress protection IP67
Impact resistance IK07
Power supply unit power supply unit not included
NotesInput Voltage: 220VAC (50-60Hz)
