Era-18F

Linear profiles for outdoor applications

W28 x L1000 x H32 18W

Order code : Era-018S27020ALB0000

Color
Optics

Technical data

specification drawing

DatasheetIES fileDWG file3DS file
  • RGB
  • complies with the European standard EN 60598-1
  • Appliance class III
  • IP67
  • IK07
Installation Linear profiles for outdoor applications
Power 18W
Power supply 24 VDC
Lumen output lm
Color 2700K, 3000K, 3500K, 4000K, 5000K, 6000K, RGB
Optics 10°, 40°, 60°x15°
Material Aluminium
Finishes Black
Efficiency 82%
Ingress protection IP67
Impact resistance IK07
Power supply unit power supply unit not included
